Engineering Information
| 8ΩStereo Power(RMS)* | 1500W×4 |
| 4ΩStereo Power(RMS)** | 2550W×4 |
| 2QStereo Power(RMS)** | 3400W×4 |
| 8ΩBridged Power(RMS)** | 5500W×2 |
| 4Ω Bridged Power(RMS)** | 6800W×2 |
| Frequency Response | 20Hz-20kHz |
| THD into 4Ω, 1KHz | <0.1% |
| SMPER IMD | <0.1% |
| Slew Rate | >10V/ us |
| Damping Factor | >300:1 |
| Input CMRR(@ 1KHz) | >60dB |
| Voltage Gain | 40× standard |
| INPUT Sensitivity(@8Ω) | 23,26,29,32,35,38,41,44dB |
| INPUT Impedance | 20KΩ/10KΩ |
| Hum and Noise | -90dB |
| Crosstalk | <60dB |
| Connectors(per channel) | Female XLR(pin2+),TRS(tip+),5-way Output binding posts, Speakon |
| Power Supply | 220V-240V~150Hz-60Hz |
| Cooling | Tow(5)variable speed DC fans |
| Controls | 2 front panel attenuators, rear panel signal ground lift jumper |
| Indicators(per channel) | PROTECT,CLIP SIGNAL,POWER,TEM,VHF,BRIDGE. |
| Protection | Temperature,DC, sub/ulfea-sonic, Shourt Circuit, lGM, Output |
| Max.Current Draw 230V | 20A |
| Dimensions (H×W×D) | 88×483×455mm(2U) |
| Gross Weight | 17.5kg |
| Net Weight | 16.5kg |
Note:
- The power marked with “*” is measured in accordance with the EIA standard.
- The power marked with “**” is measured using a 40ms pulse and a 1KHz sine wave under a total harmonic distortion of 1%.
- Power tests with “**” cannot directly use sine wave signals; otherwise, it may burn out the DC fuse or other components.
- DSL reserves the right to interpret the above parameters. Any changes in the parameters will not be notified separately.
