Engineering Information
| 8ΩStereo Power(RMS)* | 700W |
| 4ΩStereo Power(RMS)** | 990W |
| 8ΩBridged Power(RMS)** | 1980W |
| Frequency Response | 20Hz-20kHz |
| Slew Rate |
20V/us |
|
Damping Factor |
300:1 |
|
Input CMRR(@ 1KHz) |
>60dB |
| Voltage Gain | 35dB |
| INPUT Sensitivity(@8Ω) | Rated power:0.775V(1.4V) |
| INPUT Impedance | >20KΩ(Balance)/>10KΩ(Imbalance ) |
| Hum and Noise | >100dB |
| Crosstalk | >60dB |
| Connectors(per channel) | XLRTerminal( pin2+),NL4 type SPK input terminal |
| Power Supply | 220V~50Hz/60Hz |
| Cooling | Two stepless speed regulation DC strong exhaust cooling fans, air convection from front to back |
| Controls | Mode switch, sensitivity switch |
| Indicators(per channel) | Protection indicator light, distortion indicator light, signal indicator light, working indicator light |
| Protection | Dc protection, temperature protection, automatic limiting protection, overcurent protection. short-circuit protection |
| Dimensions (H×W×D) | 88×482×320MM |
| Gross Weight | 16.3Kg |
| Net Weight | 14Kg |
Note:
- The power marked with “*” is measured in accordance with the EIA standard.
- The power marked with “**” is measured using a 40ms pulse and a 1KHz sine wave under a total harmonic distortion of 1%.
- Power tests with “**” cannot directly use sine wave signals; otherwise, it may burn out the DC fuse or other components.
- DSL reserves the right to interpret the above parameters. Any changes in the parameters will not be notified separately.
